A series

Actuating shock force

98KN

98KN

98KN

98KN

Frequency of shock

6500(Time/Minute)

6500(Time/Minute)

6500(Time/Minute)

6500(Time/Minute)

Amplitude

15mm

15mm

15mm

15mm

Noise

95db(A)

95db(A)

95db(A)

95db(A)

Shock time

8(Second/Time)

8(Second/Time)

8(Second/Time)

8(Second/Time)

Overall dimension

7265*2900*4100(mm)

7265*2900*4100(mm)

6600*3470*3200(mm)

6350*3350*3200(mm)

Installed capacity

30Kw Hydraulic, 4*7.5Kw Vibration

22Kw Hydraulic, 4*5.5Kw Vibration

18.5/15Kw Hydraulic, 4/2*5.5Kw Vibration

15Kw Hydraulic, 2*5.5Kw Vibration

Weight of brick machine

15.39T

14T

8.57T

6.84T

Maximum pressure

14Mpa & 16 Mpa  Dual Pump

14Mpa & 16 Mpa  Dual Pump

14Mpa & 16 Mpa  Dual Pump

16 Mpa

Pallet size

1100*1100(mm)

1100*900(mm)

1100*700(mm)

1100*570(mm)

Product Height

30-300mm

30-300mm

30-300mm

30-200mm

A6

A5

A4

A2

A6

A5

A4

A2

A6

A5

A4

A2

Standard brick 240* 115*53mm

64

48

40

32

11520

8640

7200

4800

15Second/Time

Hollow brick 190*190*390mm

10

10

7

5

1800

1800

1260

900

20Second/Time

Interlocking brick 225*112.5*60mm

32

24

20

16

5760

4320

3600

2880

20Second/Time

Holland brick 200* 100*60mm

45

36

27

18

8100

6480

4860

3240

20Second/Time

Multi-hole brick 240* 115*90mm

32

24

20

16

5760

4320

3600

2880

Border stone 1000* 150*300mm

2

2

2

2

180

120

120

120

30Second/Time
