B Series

Actuating shock force

98KN

98KN

98KN

98KN

Frequency of shock

6500(Time/Minute)

6500(Time/Minute)

6500(Time/Minute)

6500(Time/Minute)

Amplitude

15mm

15mm

15mm

15mm

Noise

95db(A)

95db(A)

95db(A)

95db(A)

Shock time

8(Second/Time)

8(Second/Time)

8(Second/Time)

8(Second/Time)

Overall dimension

7350×3100×4330(mm)

7265*2900*4100(mm)

7100*2790*3500(mm)

7025*27903500(mm)

Installed capacity

30Kw Hydraulic, 4*7.5Kw Vibration

22Kw Hydraulic, 4*6KwVibration

18.5Kw Hydraulic, 2/4*5.5KwVibration

15Kw Hydraulic, 2/4*5.5KwVibration

Weight of brick machine

15T

12T

9.82T

6.84T

Maximum pressure

14Mpa & 16 Mpa  Dual Pump

14Mpa & 16 Mpa  Dual Pump

14Mpa & 16 Mpa  Dual Pump

14Mpa

Pallet size

1350*1150(mm)

1350*1150(mm)

1150*700(mm)

1150*570(mm)

Product Height

30-300mm

30-300mm

30-200mm

30-200mm

B6

B5

B4

B2

B6

B5

B4

B2

B6

B5

B4

B2

Standard brick 240* 115*53mm

68

51

42

34

12240

9180

7560

6120

15Second/Time

Hollow brick 190*190*390mm

15

10

7

5

2700

1800

1260

900

20Second/Time

Interlocking brick 225*112.5*60mm

36

28

28

18

6480

5040

3600

3240

20Second/Time

Holland brick 200* 100*60mm

55

40

40

20

9900

7200

4500

3600

20Second/Time

Multi-hole brick 240* 115*90mm

32

24

24

16

5760

4320

3600

2880

Border stone 1000* 150*300mm

2

2

2

2

180

120

120

120

30Second/Time
